ISUZU Sewage Suction Truck 15000L Vacuum Sewage Tanker Truck For Industrial Waste

Certification : ISO9001, ISO14001, OHSAS18001, CCC

Brand Name : ISUZU Giga

Model Number : CLW

Place of Origin : China

MOQ : 1 unit

Price : 15000-35000 per unit

Packaging Details : Nude

Delivery Time : 65 working days after deposit

Payment Terms : 50% deposit,Balance should be paid before ship out

Supply Ability : 500PCS/Week

Model NO. : ISUZU Giga

Emission Standard : Euro 6

Payload : 18T

Transmission Type : Manual

Fuel : Diesel

Tank Volume : 160000L

Drive Wheel : 4x2

Hoesrpower : 205HP

Condition : New

Name : Fecal Suction Truck

Capacity : 12cbm

Brand : ISUZU Giga

Wheels : 10

Feature : Jetting

Vacuum Pump : Morop

Transport Package : Bulk, RO-RO, Frame, Container

Specification : 10100*2500*3850mm

Trademark : ISUZU Giga

Origin : China

HS Code : 8503009090

Customization : Available

After-sales Service : 1 Year

Warranty : 12 Month

Manufacture : Chengli Special Automobile Co.,Ltd

Contact Now

ISUZU Giga Washing Fecal Suction Vacuum Sewage Tanker Truck

ISUZU Giga Washing Fecal Suction Vacuum Sewage Tanker Truck is a robust, multi-functional vehicle designed for municipal and industrial sewage treatment, septic tank cleaning, and waste management. This truck integrates powerful suction and jetting capabilities to clean and remove waste from sewers, septic tanks, and other drainage systems. The ISUZU Giga series is well-known for its reliability, fuel efficiency, and durability, making it an excellent choice for high-capacity waste management operations.


ISUZU Giga 15,000L Vacuum Sewage Tanker:
Capacity: 15,000 L septic tank

Engine: 380HP ISUZU 6WG1-TCC

Vacuum Pump: 2500 m³/h

Jetting Pressure: 250 bar

Water Tank: 4,000 L

Applications: Suitable for municipal sewage, residential septic tank cleaning, and industrial waste removal.

ISUZU Giga 20,000L Vacuum Sewage Tanker:
Capacity: 20,000 L waste tank

Engine: 450HP ISUZU 6HK1-TCC

Vacuum Pump: 3000 m³/h

Jetting Pressure: 300 bar

Water Tank: 6,000 L

Applications: Larger-scale cleaning of industrial waste, municipal sewage, and heavy-duty septic tank cleaning.

ISUZU Giga Washing Fecal Suction Vacuum Sewage Tanker Truck


Technical date
General Descriptions Specifications and types
Truck Brand CLW BRAND
Chassis Brand Giga
Approx. Dimension 10150*2550*3800(mm)
GVW./Curb Wt. 25000(Kg)/ 17435Kg
Cab Cab Capacity 2 persons' seat
Air Conditioner Air Conditioner
Chassis Drive Type 6*4,Left hand drive
Fuel Type Diesel
Engine Make & Model ISUZU
Model 6WG1-TCC
Power 300hp
Emission Standard EURO 6
Brake Air Brake
Wheelbase/No.of axle 4359+1350mm / 3
Tyre Specfication 295R20
Tyre Number 10 tyres and 1 spare tyre
Max Speed 90 km/h
Paint Automative metallic paint
Tank Capacity Vacuum Tanker:20CBM
Material Carbon Steel
Thickness 8mm
Vacuum Pump Brand morop
Produce country Italy
Model 110
Flow 984M3/H
Vacuum Pipe Length 8m
Jetting pump Brand Pinfu
Flow 330L
High Presssure 18Mpa
Reel Rotation 180 degree
Control system Hydraulic
Type Wash system
Length 60meter
Nozzle 10pcs
The interior of the sewage tank is covered with stainless steel plates, the bottom of the anti-corrosion tank is convenient for unloading, and there is a ladder inside the tank
Double roof design of the left and right oil cylinders of the tank (with buffer support rods), the lifting and lowering of the tank is more reliable, and the vehicle stability is strong
The water inlet of the water tank is a ball valve type fire hydrant (convenient to switch and durable), with a fire protection interface, with a thick liquid level tube, and with a pagoda type hand washing method valve
With water and sewage intercommunication function (DN100 bold connecting pipe)
An anti-overflow valve is installed on the top of the sewage irrigation, and a three-jaw tank mouth is installed on the bottom of the sewage irrigation (easy to clear the tank)
Both sides are tiled with patterned plate pipe platform, galvanized protective net, patterned anti-slip guardrail, beautiful and durable
There is a ladder on the side of the tank, and a checkered plate flat belt on the top of the tank, with guardrails
The operating system is neatly arranged in the operation box, and there are operating instructions and precautions (to prevent misuse)
Both the high-pressure three-way valve and the sewage suction four-way valve are equipped with shock-resistant pressure gauges with a diameter of 100 mm, which can resist the vibration of the working environment and reduce the pulsation of the medium pressure, and accurately display the actual pressure
Standard configuration is a tool box, a 100 sewage suction port, 2 100 sewage discharge ports, a 150 sewage discharge port (with ball valve booster rod) and a 600 sewage discharge port at the end (hydraulic opening, with locking device)
